Blade Tools Welding Machine
Application This device is for motor stator induction coil brazing welding treatment.
Composition Transistor tube medium frequency power supply Distant soft output cable Induction heating coil Output cable support Closed cooling water device Feature 1. Fast heating speed & less burning loss. 2. Complete restrictive protection method can guarantee the device in reliable constant operation. 3. Fully digital control for temperature control, constant power control, zero power start etc. 4. Real-time monitoring & alarm on water shortage, over-heat, over-current, over-voltage etc. 5. Movable output transformer with small size which is reliable & convenient for adjustment. 6. Induction heating coil ensures the uniform heating temperature of work-piece. |
|
Main parameters
| Model | Rated Power （KW） | Rated frequency （KHz） | Max. diameter （mm） | Max. thickness ( mm ) | Welding time ( min ) | Heating temp. ( ℃ ) | Water flow （T/h） |
| MFMB-100 | 100 | 5-15 | ￠350 | 10-40 | ≤4 | 850 | 1.5-2 |
| MFMB-160 | 160 | 6-10 | ￠550 | 10-80 | ≤4 | 850 | 1.7-2.3 |
| MFMB-250 | 250 | 6-10 | ￠750 | 10-100 | ≤6 | 850 | 3-5 |
| MFMB-300 | 300 | 4-10 | ￠900 | 10-100 | ≤8 | 850 | 4-6 |
| MFMB-400 | 400 | 3-10 | ￠1050 | 10-120 | ≤12 | 850 | 5-7 |
| MFMB-500 | 500 | 3-10 | ￠1200 | 10-150 | ≤12 | 850 | 8-10 |
| MFMB-600 | 600 | 3-10 | ￠1500 | 10-200 | ≤12 | 850 | 10-12 |
