Precious Metal Induction Melting Furnace
Usage
It is used to cast the gold/ silver ingots, jewellery and artware by the large-scale smeltery and small-size noble metal processing enterprise.
Features
Jacking from bottom or fixed-point casting structure, safety operation;
Special type of rapidly-heated and high-temperature ceramic cavity, clean smelting environment;
Optimum heating current frequency, extending the lifetime of the crucible;
Global leading induction heating system, stable & reliable;
Precise control of heating energy, meeting the requirements for various heating technologies;
Smelting under high power factor, quite low harmnoic interference on the power source;
Rapid speed of smelting, no loss of any composition of the noble metal;
Reliable monitoring of pressure on water of the system, flow rate and temperature;
Equipped with refrigerating circulating water cooling system, small space occupied;
Automatic casting system can be equipped to adapt to the casting of ingots in bulk;
Fully support 99.995 gold & silver purification and ingot casting technology .
Main technical parameters
Model | Capacity(KG) | Rated Power(KW) | Frequency Range(KHz) | Melting Temperature(℃) |
HFSC-30 | 1-5 | 30 | 10-15 | 1300 |
HFSC-40 | 5-10 | 40 | 10-15 | 1300 |
HFSC-60 | 10-15 | 60 | 4-6 | 1300 |
MFSC-100 | 30-60 | 100 | 2.5-3 | 1300 |
MFSC-160 | 100-150 | 160 | 2.5-3 | 1300 |
MFSC-200 | 200-300 | 250 | 1-2.5 | 1300 |
MFSC-300 | 500 | 300 | 1-2.5 | 1300 |
MFSC-400 | 1000 | 400 | 1-2.5 | 1300 |
Other specifications can be made-to-order as per the technology.
